標準條件:環境溫度:40℃ 海拔高度:1000m 相對濕度:60% Normal condition:ambienttemp:40℃ , altitude:1000m , relative humidity:60%
標準配置 Standard configuration | |||||||||
發動機Engine 發電機Alternator 40℃散熱水箱40℃C Radiating water tank 工業消音器/波紋管Industrinal muffler bellows 油水分離器Oil-water separator 鋼制底架Steel framel | 免維護蓄電池/蓄電池連接線/蓄電池充電器 Maintenance-free battery battery connecting wire Battery charger 輸出斷路器Output circuit breaker(800KW以下可配置) 智能控制屏Intellectual control panel | ||||||||
選用配置 Optional configuration | |||||||||
住宅型消音器Residential muffler 重型工業滅火式消音器 Heavy duty industrial extinguishing muffler 重型空氣過濾器Heavy duty aiffilter 電熱式水套加熱器Elect rothe rmic wate rjacket he 燃油式水套加熱器Fueltypewaterjacket heater 底盤油箱,日用油箱Base fuel tank Daily fuel tank 機油自動補給系統Auto lube feeding system | 燃油自動補給系統Auto fuel feeding system 自動通信控制系統 Auto communication control system 三遙通信控制系統3remote communication control system 自動并機控制系統Auto pa rallel running control system 自動電源轉換開關柜ATS panel 專用工具Special tool | ||||||||
主要技術參數 Main technical parameter
機組型號 Generating set model |
備用功率 Reserve power |
常用功率 normal power |
柴油機型號 engine model |
缸數 cylingers |
缸徑× 行程 Bore×stroke(mm) |
排氣量 (L) displacement |
燃油消耗率 Fuel consumption rate (g/kw.h) |
機組尺寸 Dimensions mm L×W×H |
機組重量 Weight | ||
KW | KVA | KW | KVA | ||||||||
SW330PG | 330 | 413 | 300 | 375 | PTAA13EG1 | 6 | 128x166 | 12.8 | 72 | 3000x1200x1400 | 2200 |
SW360PG | 360 | 450 | 320 | 400 | PTAA780G1 | 6 | 128x166 | 12.8 | 88.04 | 3100x1230x1420 | 2400 |
SW400PG | 400 | 500 | 360 | 450 | PTAA780G3 | 6 | 128x166 | 12.8 | 98.14 | 3150x1230x1436 | 2500 |
SW440PG | 440 | 550 | 400 | 500 | PTAA780G5 | 6 | 128x166 | 14.6 | 72 | 3150x1230x1436 | 2550 |
SW500PG | 500 | 625 | 450 | 563 | PTAA15EG3 | 8 | 128x142 | 14.6 | 175 | 3200x1230x1436 | 2600 |
SW550PG | 550 | 688 | 500 | 625 | PTAA1120G3 | 10 | 128x142 | 18.3 | 175 | 3250x1230x1436 | 2650 |
SW600PG | 600 | 750 | 540 | 675 | PTAA18EG5 | 10 | 128x142 | 18.3 | 175 | 3250x1400x2080 | 3575 |
SW620PG | 620 | 775 | 560 | 700 | PTAA1340G3 | 12 | 128x143 | 22 | 147 | 3600x1400x1800 | 4150 |
SW660PG | 660 | 825 | 600 | 750 | PTAA1340G5 | 12 | 128x143 | 22 | 147 | 3600x1400x1800 | 4150 |
SW704PG | 704 | 880 | 640 | 800 | PTAA22EG7 | 12 | 128x142 | 21.9 | 175 | 3600x1400x2080 | 4405 |
SW800PG | 800 | 1000 | 720 | 900 | PTAA1780G5 | 16 | 128x142 | 29 | 190.25 | 4500x1800x2100 | 6100 |
SW880PG | 880 | 1100 | 800 | 1000 | PTAA1780G7 | 16 | 128x142 | 29 | 207 | 4500x1800x2100 | 6100 |
SW1000PG | 1000 | 1250 | 900 | 1125 | PTAA2230G1 | 20 | 128x142 | 37 | 178 | 5000x2140x2420 | 7380 |
SW1100PG | 1100 | 1375 | 1000 | 1250 | PTAA2230G3 | 20 | 128x142 | 37 | 178 | 5000x2140x2420 | 7380 |
SW1200PG | 1200 | 1500 | 1100 | 1375 | PTAA37EG5 | 20 | 128x142 | 36.5 | 178 | 5000x2140x2420 | 7380 |
SW1320PG | 1320 | 1650 | 1200 | 1500 | QTA3240G5 | 12 | 170x195 | 53 | 301.71 | 5400x2190x2740 | 10500 |
